It provides a fully featured commentator position and a line-level input. The unit has an individual commentator output, with an additional output providing a mix of commentator and line input audio. A limit indicator on the main panel shows when the adjustable limiter on the main output is active, and a bright 21 segment LED PPM meter, which can be disabled, shows the main output level.
Features of the CM-CU1 Commentator Unit
- Commentator position with individual output; plus main mix output.
- Line input with configurable output and headphone presence.
- Talkback outputs selectable by the commentator, with built in limiter and adjustable gain.
5 Return audio circuits that are routed to headphones along with the commentator input. Any
- source can be individually level controlled and sent to left, right or both ears.
- A wide input gain range and switchable phantom power allows support of a variety of - microphone types including low output ribbon, headsets and high output phantom powered - microphones.
- User preset adjustable limiter on main output with limit activity indication.
- Built in line-up tone for initial cabling checks.
- 21 Segment LED PPM meter showing main output level.
- Transformer balanced inputs and outputs.
- Fitted formica ‘Sharpie’ designation strips.
- Robust mechanical design with protection for potentiometer knobs.
- Universal AC mains, or 12-24 volt DC power.
