קונסולה דיגיטלית All-in-one

Control Panel

·         Frames with 16, 24 and 40 faders

·         Six banks each with 2 layers

·         100 mm fader + 1 freely assignable rotary knob + channel display for each fader with sensetriggered pop-up displays for modules

·         TFT metering: mono, stereo or up to 7.1 including bus assignment, gain reduction for dynamics, AfV status, VCA assignment, mix-minus

·         GUI page output, e.g. metering, on an external monitor

·         Eight central user buttons

·         40-bit floating point

·         Up to 184 inputs with A/B input, up to 32 sub-groups, 32 aux sends, up to 32 track buses, up to 16 main sums

·         Rapid switching of channel and bus to mono / stereo / surround

·         Up to 24 surround channels, 128 VCA groups with metering, 256 GPC channels

·         Surround formats: DTS / Dolby ® Digital 5.1, Dolby ® Pro Logic 4.0, DTS ES / Dolby ® EX 6.1, SDDS 7.1, DTS-HD 7.1, diverse panning characteristics, surround aux bus

·         Two AFL: 1 surround 8-channel, 1 stereo

·         Two PFL stereo

·         Audio-follow-Video with 128 events, control via Remote MNOPL, Ember+, GPI or matrix connection, envelope up to 10s fade time

·         Solo In Place

·         Permanent input meter beside fader, adjustable INPUT, PF, AF, DIROUT meter point in channel display

·         Loudness Metering according to EBU R128 and ATSC A/85, momentary or short term in every channel, integrated measurement on sum channels with display of integrated LUFS value in headline.

·         Modules: INMIX with MS decoder, digital amp, 2-band fully parametric filter, 4-band fully parametric EQ, 2-band fully parametric side-chain filter, insert, delay up to 1800 ms – switchable units: meters, milliseconds, frames, 4 independent dynamic modules: expander, gate, compressor, limiter, image, meter, direct out

·         AMBIT Upmix, available on every 5.1 channel, fully Downmix compatible

·         Inline configuration with send / return switching — per channel or global

·         Fully-equipped surround channel with coupling of all channel parameters and hyperpanning

·         512x512 matrix, non-blocking

·         96 kHz, 24-bit

·         Level adjustment for all inputs and outputs

·         Downsizing from surround (up to 7.1) to stereo

·         Integrated monitoring devices for remote locations, e.g. director’s room

·         Networking with up to 14 Nova73 cores, share and import of sources and destinations, studio intervention
