Superb High-definition Image
UV570 adopts 1/2.8 inch, 2.07 megapixel high quality CMOS sensor. Resolution is up to 1920x1080 with frame rate up to 60fps.
Multiple Optical Zoom Lens
5X,10X,12X,20X and other optical zoom lens for options. The lens adopts 83.7° wide angle without distortion.
Leading Auto Focus Technology
Leading auto focus algorithm makes lens auto focus more quickly, accurately and stably.
Low Noise and High SNR
Low Noise CMOS effectively ensure high SNR of camera video. The adoption of advanced 2D/3D noise reduction technology not only further reduces the noise, but also ensuring image sharpness.
Multiple Audio Output Interfaces
Support HDMI, SDI, CVBS, USB2.0, USB3.0, LAN; HDMI, SDI, LAN interfaces support audio and video simultaneous output; SDI supports to transmit 100 meters under the 1080P60 format.
Multiple Audio/Video Compression Standard
Support H.264/H.265 video compression, AAC, MP3 and G.711A audio compression and 1920x1080 resolution with frame rate up to 60fps compression; Support 8000, 16000, 32000, 44100, 48000 sampling frequency.
Audio and Video Storage
USB2.0 interface supports U disk storage function, real-time recording and storage.
Built-in gravity sensor
Built-in gravity sensor, support the automatic flip function of the gimbal, convenient for engineering installation.
Multiple Network Protocols
Support ONVIF, GB/T28181, RTSP, RTMP protocols , RTMP push mode, which is easy to link streaming media server (Wowza, FMS), RTP multicast mode and network full command VISCA control protocol.
Control interface: RS485, RS232; RS232 support cascade, easy to install and use.
Multiple Control Protocol
Support VISCA, PELCO-D, PELCO-P protocols and Automatic identification protocol.
Extremely Quiet PTZ
Adopting step driving motor mechanism and motor drive controller with high precision is to ensure PTZ works smoothly with low speed and without noise.
Low-Power Sleep Function
Support low-power sleep/wake up, the consumption is lower than 400mW under sleep mode.
Multiple Preset: Support 255 preset positions (the remote controller is set to 10preset positions).
Multiple Remote Controller
Users can choose infrared remote controller or wireless remote controller according to the environmental conditions.2.4G wireless remote controller is not affected by the angle, distance, infrared interference.
Tele-education, Lecture Capture, Webcasting, Videoconferencing, Tele-training, Tele-medicine, Interrogation and Emergency command systems
