SPECIFICATIONS:
CH 1 & 2
Mic Inputs:
- Input Type: XLR
- Input Impedance: 4k (2k with pad)
- Input Sensitivity: Minimum : 3mV RMS (-51dBV) (Without Pad) - Nominal: 22mV RMS (-33dBV)
- Max Input Level: Pad Off: 649mV RMS (-3.8dBV) Pad On: 6.5V RMS (16.3dBV)
- Pad: -20dB
- Phantom Power: +24V
Line Inputs:
- Input Type: 1/4" TRS
- Input Impedance: 10k
- Input Sensitivity: Minimum: 14mV RMS (-37.2dBV) Nominal: 112mV RMS (-19dBV)
- Max Input Level: 3.2V RMS (10dBV)
CH 3
- Input Type: Left/Right RCA, 1/8" TRS
- Input Impedance: 15k Min
- Input Sensitivity: Minimum: 159mV RMS (-16dBV) Nominal: 495mV RMS (-6.1dBV)
- Max Input level: 15.8V RMS (+24dBV)
CH 4
- Input Type: Left/Right RCA
- Input Impedance: 15k Min
- Input Sensitivity: Minimum: 159mV RMS (-16dBV) Nominal: 495mV RMS (-6.1dBV)
- Max Input level: 15.8V RMS (+24dBV)
Main RCA Outputs
- Nominal Output Level: 1V RMS (0dBV)
- Maximum Output: 2.9V RMS (9.2dBV)
Mono Outputs
- Nominal Line Level Output: 1V RMS (0dBV)
- Maximum Line Level Output: 2.9V RMS (9.2dBV)
- Nominal Mic Level Output: 32mV RMS (-30dBV)
- Maximum Mic Level Output: 99mV RMS (-20.8dBV)
Headphone Outputs
- Power Output: 30mW Stereo @ 32 Ohm
Distortion
- THD: 0.01% (22Hz – 22KHz @ Nominal Volume)
Noise
- S/N: >80dB
Misc
- Batteries: 2 x AA (Alkaline)
- Typical battery Life: About 15 Hours
- DC In Requirements: 4.5VDC (regulated), 500mA minimum.
- Barrel plug: 4mm O.D. and 1.74mm I.D., center positive.
Dimensions
7.2" x 4" x 2.1" (L x W x H) (182.4 x 102.3 x 53 mm)
