DANTE/AES67

Monitoring of 64 Dante channels at 48kHz (32 channels at 96kHz)
Output up to 64 Dante channels at 48kHz (32 channels at 96kHz)
Sample rates supported
- 1kHz
- 48kHz
- 88.2kHz
- 96kHz
Bit Depth supported
- 16bit
- 24bit
- 32bit
AES67 compatible
Fully compatible with New Dante Domain Manager
Two main modes of operation:
- User defined mix to L and R output - 8 User memories with customizable names
- PFL mode where selected channel is sent to LR with two modes: Auto cancel previous selection; Additive with Clear button
64 channel meters
- High resolution meters
- Optional Peak indicator with user definable trigger level
Main LR meters
- Large high-resolution meters displaying 0dBFS down to -60dBFS in 1dB steps
- Optional Peak hold
- Optional Working level indicator with user definable level
Internal 25W/channel amplifier feeding either
- 2x 63.5mm full range drivers in optimized ported cabinets
- Headphone output
Dual Balanced Line Outputs 0dBFS = +21dBu maximum output into 600ohms 2x 3pin male XLR connectors
- Fed from main Stereo LR bus
- Option to follow main volume control
- User adjustable trim (0dB to -60dB in 1dB steps)
- Output Mute relays
Stereo AES output on 3pin male XLR connector
- Fed from main Stereo LR bus
- Option to follow main volume control
- User adjustable trim (0dB to -60dB in 1dB steps)
Stereo AES Input on 3pin female XLR connector
- User selectable routing to Dante output(s)
Stereo unbalanced line input on 6.35mm stereo jack
- with input level trim control suitable for use with common music playback devices such as, iPods, iPhones, MP3 players
- max input level +8.5dBu
35mm Headphone socket and microphone input
- Headphone output for driving loads from 8ohm to 600ohm
- Microphone input with gain control (up to 40dB) and level trim
- Socket wiring is suitable for use with most common mobile phone headsets
Dual 1GHz RJ45 Dante inputs
- 1GHz or 100MHz operation
- User configurable for Switched or Redundant operation
- Network configuration information available via menu
Power input via
- 2x IEC mains socket
- 90-250V 50-60Hz mains input
- Both power inputs can be active at the same time for redundancy
USB port is used for product firmware updates
Internal oscillator with selectable routing to Dante output(s) and level control
- Sine/Square/Triangle Wave generation settable to a frequency of 50Hz, 100Hz, 200Hz, 500Hz, 1kHz, 2kHz, 5kHz and 10kHz
- White Noise Generator
- Pink Noise Generator
LCD
- 0” (127mm) diagonal 24bit colourLCD with 800xRGBx480 resolution
- LED backlight (adjustable brightness via software)
- 5-point touch capacitive touch overlay with gesture support
Size
- 494mm wide by 300mm deep by 88mm height
- 1.5kG
19 inch rack mounting ears can be removed for desktop use
