The Audio Sentinel®+» Web/RJ can be configured and monitored locally and/or remotely over any IP network, including private networks, IP-based industrial control networks, and the Internet. Users can operate this product using a desktop web browser or web-enabled (HTML5) mobile device. App Store not required. Email and SMS-email notification can be configured to alert up to eight recipients when silence or out-of-phase audio is detected. SMTP username and passwords using STARTTLS (Gmail, etc.) or Base64 authentication are supported. SNMP traps and SET/GET are built-in, allowing multiple units to be monitored and configured with SNMP management software.

Features/Benefits

• • Built-in web server provides simple, web-based (HTML5) notification, monitoring, configuration, and control.
• • Powered by a high-performance ARM® Cortex™ processor.
• • Support for STARTTLS secure SMTP authentication (Gmail, etc.)
• • Front panel, remote, and web-based switcher controls.
• • Both stereo inputs feature silence sensors/phase monitors with front panel activity and alarm LED indicators.
• • Silence trip level detection from -15dB to -35dB in 1 dB steps for each stereo channel.
• • Precise alarm time delay from 0(OFF) to 65535 seconds (18 hours, 12 min and 15
  sec’s). in one-second increments for each channel.
• • Alarm restore time delay from 0(OFF) to 65535 seconds (18 hours, 12 min and 15
  sec’s). in one-second increments for each channel.
• • Internal, transparent, 2×1 switcher with mechanical latching relays.
• • If power is lost, the last selected channel is passed to the output.
• • Email notification may be configured to alert up to EIGHT recipients when alarms
  are detected.
• • Email logging of system status, along with the site ID may be emailed in time
  spans from once an hour to once a day.
• • Pluggable screw terminal block and RJ45 audio jacks for stereo inputs and output.Fully RFI proofed.
• • Surge protected internal power supply, universal switching power supply with domestic connector supplied. International power supply optional.
• • Up to two units may be mounted on the optional RA-1 rack shelf.
