ייצוב חשמל

Furman

P-1400 AR E

הגנה מקפיצות מתח, רעשים במערכת החשמל, וכיבוי בטוח של מכשירי אודיו עד 30A עם מחברי C-FORM לעומס גבוה

The P-1400 AR E accepts any input voltage from 188V to 270V and transforms it to a constant output of 230V or 240V (switchable), ±10V. Voltages beyond that range may also be converted to usable levels, depending on the range variance.

Additionally, the P-1400 AR E is a full-featured power conditioner that filters and purifies AC power, reducing line noise and ensuring optimum performance. Not only will your equipment perform better with Furman’s Linear Filtering Technology (LiFT), but it will also be fully protected by our exclusive Series Multi-Stage Protection (SMP), and Extreme Voltage Shutdown (EVS). This circuitry provides the highest level of power protection available.

Specifications

MAXIMUM OUTPUT CURRENT:
- 6 amps @ 230 volts (230V output setting – 240V @ 240V output setting)
LINE CORD:
- Detachable 2.5 meter, black cord with Schuko plug (standard)
BNC SOCKET WITH SWITCH FOR REAR RACK LAMP:
- 12VAC 500mA max (lamp not included)
IN REGULATION RANGE:
- 182 to 262 VAC (230V output setting), 188 to 270 VAC (240V output setting)
OVER VOLTAGE SHUTDOWN:
- 275 VAC nominal
SPIKE PROTECTION MODES:
- Line to neutral, zero ground leakage
SPIKE CLAMPING VOLTAGE:
- 376 VAC peak @ 3,000 amps
RESPONSE TIME:
- 1 nanosecond
MAXIMUM SURGE CURRENT:
- 6,500 AMPS
NOISE ATTENUATION:
- 10 dB @ 10kHz, 40 dB @ 100kHz, 50 dB @ 500kHz
DIMENSIONS:
- 19” W x 12.0” D x 1.745” H
WEIGHT:
- 9.5 kg.
POWER CONSUMPTION:
- (No load) 5 Watts

קישור לאתר החברה

מדריך למשתמש

סיקוונסר, סינון רעשים והגנת AC מתקדמת עד 6A
