ממיר MADI-ANYTHING

Features

• Two MADI SFP ports, accepting ANY brand of SFP
• Built-in wordclock IN/OUT
• AUX port accepting any of the AUX Cards as conversion source/destination
• When combined with AUX-MADI-COAX-DUAL or AUX-MADI-SFP-DUAL, it acts as MADI/MADI bridge with full network and clock domain separation, for up to 64x64ch at 96kHz. Other targets (e.g. DANTE) can be realized with the appropriate AUX card
• 64x64ch bi-directional Sample Rate Converter with top-notch specifications (>120dB THD+N, >134dB DNR), can be bypassed when desired
• Supports sample rates from 44.1 to 192kHz on either side
• FlexLink port for lowest latency, bi-directional transfer of 192 channels audio, clock and power
• Remote control via USB: web remote (no software required), or UART command line
• Triple-redundant power supply

Additional features when connected to the MVR-mkII

• True channel-wise routing of all available channels (built-in plus AUX card)
